IPS (In-Plane Switching) Displays

You are here: Home > Products > Displays > Colour Displays > IPS (In-Plane Switching) Displays

IPS TFT displays

IPS displays offer significant performance improvements over standard TFTs, enabling designers to add an enhanced look and feel to their products.

  • Free viewing angles
  • High contrast ratios
  • Fast data transfer speeds
  • 24-bit colour depth
  • Greater colour accuracy
  • Extensive options for display customisation

Check out our range of IPS TFT displays below or get in touch today to discuss the benefits of adding IPS displays to your next product design.

Get in touch today





1.5" IPS TFT - IPS015B101A

  • Resolution (pixels): 320 x 320
  • Brightness (cd): 430
  • Interface Type: RGB / SPI

Find out more

Specification

2.1" IPS TFT - IPS021B101A

  • Resolution (pixels): 480 x 480
  • Brightness (cd): 250
  • Interface Type: MCU

Find out more

Specification

2.5" IPS TFT - IPS025B101A

  • Resolution (pixels): 480 x 480
  • Brightness (cd): 400
  • Interface Type: MIPI

Find out more

Specification

2.8" IPS TFT - IPS028A101A

  • Resolution (pixels): 240 x 320
  • Brightness (cd): 200
  • Interface Type: MCU

Find out more

Specification

2.9" Ultra-wide IPS TFT - IPS029A110A

  • Resolution (pixels): 376 x 960
  • Brightness (cd): 300
  • Interface Type: MIPI / RGB+SPI

Find out more

Specification

3.5" IPS TFT - IPS035A101A

  • Resolution (pixels): 320 x 480
  • Brightness (cd): 250
  • Interface Type: MCU/RGB

Find out more

Specification

4" IPS TFT - IPS040A101A

  • Resolution (pixels): 480 x 480
  • Brightness (cd): 300
  • Interface Type: RGB

Find out more

Specification

4.3" IPS TFT - IPS043A101A

  • Resolution (pixels): 480 x 800
  • Brightness (cd): 400
  • Interface Type: RGB

Find out more

Specification

4.3" High Temp. Range, Sunlight Readable IPS TFT - IPS043B101S

  • Resolution (pixels): 480 x 272
  • Brightness (cd): 1000
  • Interface Type: RGB 24-bit

Find out more

Specification

4.3" IPS TFT Integrated Display Solution - IPS043A104R

  • Resolution (pixels): 480 x 272
  • Brightness (cd): 250
  • Interface Type: HDMI

Find out more

Specification

5.0" IPS TFT - IPS050A101A

  • Resolution (pixels): 720 x 1280
  • Brightness (cd): 300
  • Interface Type: MIPI

Find out more

Specification

5.0" IPS TFT Integrated Display Solution - IPS050A102R

  • Resolution (pixels): 800 x 480
  • Brightness (cd): 1000
  • Interface Type: HDMI

Find out more

Specification

5.0" High Temp. Range, Sunlight Readable IPS TFT - IPS050A104S

  • Resolution (pixels): 800 x 480
  • Brightness (cd): 1000
  • Interface Type: RGB

Find out more

Specification

5.0" Transflective IPS TFT - IPS050A105C

  • Resolution (pixels): 800 x 480
  • Brightness (cd): 40
  • Interface Type: RGB

Find out more

Specification

6.8" Ultra-wide IPS TFT - TFTL-0107

  • Resolution (pixels): 480 x 1280
  • Brightness (cd): 400
  • Interface Type: MIPI

Find out more

Specification

7.0" IPS TFT with Touchscreen - IPS070B101B

  • Resolution (pixels): 720 x 1280
  • Brightness (cd): 420
  • Interface Type: MIPI

Find out more

Specification

7" Sunlight Readable IPS TFT - IPS070A106C

  • Resolution (pixels): 1024 x 600
  • Brightness (cd): 800
  • Interface Type: LVDS

Find out more

Specification

7.0" IPS TFT Integrated Display Solution - IPS070A107R

  • Resolution (pixels): 1024 x 600
  • Brightness (cd): 250
  • Interface Type: HDMI

Find out more

Specification

7.0" High Temp. Range IPS TFT - IPS070A108S

  • Resolution (pixels): 800 x 480
  • Brightness (cd): 650
  • Interface Type: RGB 24-bit

Find out more

Specification

7.8" Ultra-wide IPS TFT - IPS078A110A

  • Resolution (pixels): 1280 x 400
  • Brightness (cd): 500
  • Interface Type: MIPI

Find out more

Specification

8.0" IPS TFT - IPS080A101A

  • Resolution (pixels): 800 x 1280
  • Brightness (cd): 320
  • Interface Type: MIPI

Find out more

Specification

9" Ultra-wide IPS TFT - IPS090B101A

  • Resolution (pixels): 1280 x 240
  • Brightness (cd): 600
  • Interface Type: LVDS

Find out more

Specification

10.1" IPS TFT - IPS101B101A

  • Resolution (pixels): 1280 x 800
  • Brightness (cd): 320
  • Interface Type: LVDS

Find out more

Specification

10.1" IPS TFT Integrated Display Solution - IPS101A105R

  • Resolution (pixels): 1280 x 800
  • Brightness (cd): 500
  • Interface Type: HDMI / VGA

Find out more

Specification

10.1" WUXGA IPS TFT - IPS101A106A

  • Resolution (pixels): 1920 x 1200
  • Brightness (cd): 300
  • Interface Type: MIPI

Find out more

Specification

10.25" Ultra-wide, High Temp. Range IPS TFT - IPS102A101S

  • Resolution (pixels): 1920 x 720
  • Brightness (cd): 600
  • Interface Type: LVDS

Find out more

Specification

15.6" IPS TFT - IPS156A101A

  • Resolution (pixels): 1920 x 1080
  • Brightness (cd): 300
  • Interface Type: eDP

Find out more

Specification

15.6'' Industrial IPS TFT - IPS156A102A

  • Resolution (pixels): 1920 x 1080
  • Brightness (cd): 500
  • Interface Type: eDP

Find out more

Specification

IPS displays offer significant performance improvements over standard TFTs, enabling designers to add a modern look and feel to their products, comparable with smartphones and tablets, but at an affordable price.  These displays offer 'free' viewing angles, making them ideal for "walk past" applications such as point of sale, and 24-bit colour depth and greater colour accuracy make them ideal for applications such as image or video processing where true colour is essential.

GTK can provide a variety of product enhancements, such as multi-point capacitive touch panels and Touchless UI solutions, specialising in customisation and bespoke design right down to the interconnect with your board. We can provide a solution optimised to your design and production requirements.
