Standard DisplayPort

Standard DisplayPort connectors

Can't find the right DisplayPort connectors?

Standard DisplayPort connectors for transmitting high definition audio/video signals, designed to replace the DVI and VGA connector interface.

Part Number	No. of Contacts	Orientation	Shielding Type	Mounting Style	Feature	Contact Plating	Drawing	Samples
DPT-R1HF1G2P-R	20	Horizontal (R/A)	With flange	SMT	Locating posts	30µ" gold
DPT-R1HNG2P-R	20	Horizontal (R/A)	No flange	SMT	Locating posts	30µ" gold

Part Number

No. of Contacts

Orientation

Shielding Type

Mounting Style

Feature

Contact Plating

Drawing

Samples

DPT-R1HF1G2P-R

Horizontal (R/A)

With flange

SMT

Locating posts

30µ" gold

DPT-R1HNG2P-R

Horizontal (R/A)

No flange

SMT

Locating posts

30µ" gold
