3.5" TFT Display (TFT-0107)
This 3.5" colour 320 x 240 px TFT display features slim bezels, making it ideal for compact and lightweight designs requiring a high resolution and colour display.
This display can be fitted with a capacitive touchscreen or assembled with a custom cover lens to form a high quality but economical user interface.
Display Features
- Size: < 5"
- Type: TN TFT
Display Specs
| Part Number | TFT-0107 |
| Display Type | TN TFT |
| Screen Size | 3.5" |
| Resolution | 320 x 240 |
| Shape | Standard |
| Aspect Ratio | 4:3 |
| Viewing Angle | 12 o'clock |
| Brightness | 275 cd/M² |
| Backlight Half-Life | 20K Hours |
| Contrast Ratio | 500:1 |
| Interface | RGB |
| Connection | ZIF |
| Operating Temperature Range | -20°C to 70°C |
| Dimensions (W x H x D) | 76.9 x 63.9 x 3.1 mm |
| Active Area (W x H) | 70.1 x 52.6 mm |
